We are a nonwoven machine manufacturer with 10+ years experience in production and installation.
Mainly include:
Spunbond Machines (S, SS, SSS),
Meltblown Machines (M),
Spun-melt Machines (SMS, SMMS, SSMMS),
PET Nonwoven Machine,
PLA Nonwoven Machine,
Bicomponent Nonwoven Machine, etc.
The Advantage of HG Nonwoven Fabric Making Machines: 1.High accurate raw material blender for polyproplyene and additives; 2.High capacity extrusion machine with good screw and barrel; 3.High performance melt filtration system; 4.High Speed with high accurate melt pump; 5.Lastest melt flow design and spinning system; 6.Well-know PLC control system and motors; 7.Smart operation program and monitoring syustem;
Technical Parameters:
| Model | Effective width | Daily capacity | Speed | Spinning system | GSM Range | Machine dimension Length*Width*Height |
| WX-1600M | 1600MM | 2000Kg | 100M/Min | Meltblown | 10-200 | 15*8*8 meter |
| WX-2400M | 2400MM | 3000Kg | 15*10*8 meter | |||
| WX-3200M | 3200MM | 4000Kg | 15*12*8 meter | |||
| WX-1600S | 1600MM | 5000Kg | 200M/Min | Spunbond
(S) |
10-200 | 20*8*11 meter |
| WX-2400S | 2400MM | 7000Kg | 20*11*11meter | |||
| WX-3200S | 3200MM | 10000Kg | 20*15*11meter | |||
| WX-1600SS | 1600MM | 9000Kg | 350M/Min | Spunbond
(SS) |
8-150 | 35*10*11meter |
| WX-2400SS | 2400MM | 13000Kg | 35*12*11meter | |||
| WX-3200SS | 3200MM | 16000Kg | 35*15*11meter | |||
| WX-1600SSS | 1600MM | 12000Kg | 400M/Min | Spunbond
(SSS) |
8-100 | 40*10*11meter |
| WX-2400SSS | 2400MM | 16000Kg | 40*12*11meter | |||
| WX-3200SSS | 3200MM | 23000Kg | 40*15*11meter | |||
| WX-1600SMS | 1600MM | 10000Kg | 400M/Min | Spunbond/
Meltblown/ Spunbond/ |
8-80 | 40*15*11meter |
| WX-2400SMS | 2400MM | 14000Kg | 40*18*11meter | |||
| WX-3200SMS | 3200MM | 18000Kg | 40*25*11meter | |||
| WX-1600SMMS | 1600MM | 12000Kg | 500M/Min | Spunbond
Meltblown Meltblown Spunbond |
8-80 | 45*15*11meter |
| WX-2400SMMS | 2400MM | 17000Kg | 45*18*11meter | |||
| WX-3200SMMS | 3200MM | 23000Kg | 45*25*11meter |
Process:
Machine Parts:
